SiRUBA F007K/KD Series

Features

Upper Thread Gripper	The Recessed Machine Bed	Cover seaming with adjustable folder, flexible presser foot, accommodate wider range of sewing items.
Newly designed auto trimmer trims precisely and stably.	The sewing material is closer to the needle and the sewing is precise, which makes sewing operation easier and smoother.

Auto Trimmer with newly designed pneumatic / electric trimming system.	trims precisely and stably, lower sound and easy to adjust.

		General Seaming / Bottom Heaming
W121 : W122 : W123 : W162 : W162H :	Light Material Medium Material Heavy Material High needle bar stroke High needle bar stroke Long stitch Length (6mm)	Basic model of interlock stitch machine with double side cover-stitching.It is avaible for various sewing by optional devices. Such as plain seaming or bottom heaming for underwear,s, sportwears, etc.. (equipped with adjustable hemming set)

Optional Device
UTG, UTH, UTJ, UTK, FL

F007K-W222-356/FQ/FEC	F007K-W222-356/FFD	F007K-W222-356/FFP

FQ Tape Binding	FFD / FFP:TAPE BINDING WITH ELASTIC BAND
For tape binding on openings of leg or neck of underwears, T-shirts, etc.. Also can attach electric (FEC) or pneumatic (FAC) tape cutter to save tape and increase sewing efficiency.	Top feeding device controls the elastic band's tension. Elastic band right-left position controller (by knee-pushing) sets the materials joining at the beginning and ending of waistband, leg opening of briefs...etc.
	FFD : Gearbox type for accurate tension control. FFP : Spring type for tension control.

« Optional device for the above model
FNC. FSC :
Sensor type rear cutter with direct-drive servo motor

Optional Device
FA, LF-A,FAC,FEC,LS-A

	Ornamental Type Binding
	Suitable for ornamental type binding of neck band, bottom or cuff of T-shirts, shirts, etc...
	Optional Device FA

F007K-W222-356/FDC	F007KD-W322-356/FDE/UTJ/

	OPTIONAL DEVICE
	UTG, UTH, UTJ, UTK

	OVERLOCK-SEAM COVERING STITCH
	FDC Fold-down type : For-4thread overlock-seam covering stitch. FDE Flattening type : For 3-thread overlock-seam covering stitch, and an extra guide of overlock-seam (FDC specification, fold-down type)is included in the accessory box.

F007K-W522-240/FR/FE/FAC	SMK	STC

Elastic / Lace Attaching with right side fabric trimmer
Top Feeding devices ensure even length and tension controlled by electric digital controller with right side fabric trimmer for elastic or lace attaching smoothly and properly on women’s underwears.

FFC : Mechanic type tape feeding.

F E : Simple electric type tape feeding.

SMK : Electric metering type tape feeding.
» SMK1-C-01 with synchronizer for simple servo motor or clutch motor
»SMK1-C-02 Connected to servo motor by encoder cable

STC : Tension sensor type tape feeding.
» STC1-U-01 with synchronizer for simple servo motor or clutch motor
» STC1-U-02 Connected to servo motor by encoder cable

Optional Device
FAC, FEC, LF-A, LS-A

F007K-W522-240/FR/FQS		SMK	STC

Fine tape Binding (Right Side Fabric Trimmer Model With Small Binder)
This machine is applicable for fine tape binding of women’s underware or T-string. Before tape binding, the fabric edge is trimmed by the right trimmer. This solves the problem of bad binding, which the tape is not sewn on the fabric. The below tape feeding devices are applicable.

SMK :	STC :
Electric metering type tape feeding.	Tension sensor type tape feeding.
SMK1-E-01 with synchronizer for simple servo motor or cluth motor.	STC1-S-01 with synchronizer for simple servo motor or cluth motor.
SMK1-E-02 Connected to servo motor by encoder cable.	STC1-S-01 Connected for servo motor by encoder cable.

OPTIONAL DEVICE
FAC, FEC, LF-A, LS-A, TUA

F007K-U122-232/FP
	Pintuck Seaming To sew a decorative convex stripe on sportswears, jeans or other clothes, can also add extra stripe inside convex to increase the effects of convexity and decoration.

F007K-U613-256/FBP
	Belt-Loop Seaming Mass production for belt loop by using stripped tape

OPTIONAL DEVICE
LF-A, LS-A

F007K-U712-264/FSP	Tape Attaching (Two Needle, Two Looper)
	This machine is specially for tape binding on cross seaming of men's briefs or sportswears to strengthen plain seam and for ornamental purpose. U 7 1 2 : finished tape width 10mm U712A : finished tape width 12mm
Optional Device	Tape Attaching ( Four Needle, Two Looper)
LF-A, LS-A	This machine is specially for tape binding on cross seaming of men's briefs or sportswears to strengthen plain seam and for ornamental purpose.

F007K-U712-264/FSR	LAP SEAMING
	Differential ratio of left and right feed dog can be adjusted separately for lap seaming to ensure symmetrical length to both left and right fabric. Applicable to trousers, casual pants and jeans, etc.


F007K-W722-388/FY	POCKET LINING SEAMING This is a 3 needles 3 loopers 1 spreader machine, and special for seaming the shell fabric and lining of pocket in trousers or work pants in simple operation to increase sewing quality and efficiency.

	FOUR-NEEDLE FLAT SEAMING For flat seaming 2 pieces of fabric. Equipped with fabric guide for easy operation
		FW- 4	4 needles Without retainer, applicable to upper thread trimmer
F007K-W922-456/FW	OPTIONAL DEVICE	FW- 4A	With special needle plate E1838P, applicable to shoe decoration
	UTH , UTK	FW- 5	4 needles with retainer, not applicable to up per thread trimmer
