| 1. With black diamond bar and bearing thread take-up lever, through the solid oil micro-oil lubrication, to prevent the fabric oil, clean and durable. | 2. Expand the available of stitching for thickness fabric. In the case of medium and thick material specifications, the stability of the stitch can be improved by improving the thread take-up. Expand the seam of the thic material sewing, and enhance the response force of the fabric. | 3, Shortened length of sewing (short thread size) By improving the trimmer structure, so that the length of the line shorter. The sewing thread after the work can be reduced. |
 |  |
|
| 4. Thread take-up with self-return. Self-return, efficient. | 5. Support double pedal, left pedal and right pedal can be separated from the operation, sewing special products, positioning easier. | 6. Support USB data interface. support USB data interface access memory bigger, storage faster. |
 |  |  |
Brethren BF-D-430-01
Electronic Bar
Tacking Machine
| Specification | BF-D-430-01 |
|---|---|
| Use | Bar Tacking |
| Max. Sewing Speed | 3200 RPM |
| Sewing Area (X x Y) | Max.40 x 30mm |
| Feed Way | Intermittent Feed (Pulsed Motor Drive Mode) |
| Stitch Length | 0.05-12.7mm |
| Max. Number og Stitches | 5000 Needle / 1 Pattern |
| Oil Supply | Micro-oil Supply |
| Presser Foot Drive Mode | Pulsed Motor Drive Mode |
| Height of Presser Foot | Max. 17mm |
| Hooks | Semi-Rotating Standard Rotary Hook |
| Thread Wipe Device | Standard Equipment |
| Trimmer Device | Standard Equipment |
| Thread Catch | Option |
| Data Storage | USB Flash Card (Using SD card can add any pattern) |
| External Data Storage Medium | U |
| Number of Cycle Programs | Max. Up to 30 (each 50 steps) |
| Storing Data | Has set up 89 kinds patterns (add up to 512 kinds of patterns, additional total needle number of about 500000 pin) |
| Motor | AC Servo Motor 550W (Direct Drive) |
| Power Supply | Single Phase 220V |
| Weight | Head about 57kg, operation panel : about 0,4kg, control box : about 9kg |
